Giant REVOLT X
ADVANCED PRO 1

Giant REVOLT X
ADVANCED PRO 1

Giant

Giant Revolt X Advanced Pro 1 Cordovan/Copper Coin

£5,499.00
Size Guide
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined

Hassle free returns

We are pleased to offer a 90 day online return policy on both bikes and accessories purchased online. All we ask is that the item is returned to us in an unused condition and with its original packaging.

Click to message
If you require any additional information, including product availability, order information or returns then please feel free to contact us via the WhatsApp messaging service!

  • We are pleased to offer a 90 day online return policy on both bikes and accessories purchased online. All we ask is that the item is returned to us in an unused condition and with its original packaging.
  • We will refund postage costs on any faulty or damaged items but not if the item was incorrectly ordered.
  • Refunds will only be returned to the original purchaser using the original payment method — refunds usually take 3-4 working days, but it could be longer depending on your bank
  • If you have a damaged or faulty item we will send you out a replacement as soon as the returned item is received. Please note that if an item has been damaged through rider neglect, misuse or wear and tear , then it will not be covered by manufacturer’s warranty. We advise you to check the individual manufacturer’s warranty policy to see whether the specific problem or issue you are experiencing is covered.
  • We would ask you to fully check the goods once received to ensure that they are as you required. Any subsequent use will be deemed acceptance of the goods.
  • We are happy to discuss Returns procedure – please give us a call or drop us an email at orders@cycleworld.co.uk.

Giant Revolt X Advanced Pro 1 Cordovan/Copper Coin

Season:2023

Brand:Giant

Code:2312028CordovanCPRCoin

WASHBOARD DESCENTS, SKETCHY DIRT, GRAVEL AND ROCKS OF ALL SHAPES AND SIZES. YOU NEVER KNOW WHAT YOU’LL GET ON A GRAVEL RIDE. THIS NEW COMPOSITE GRAVEL MACHINE FEATURES A SUSPENSION FORK AND ENGINEERED COMPLIANCE TO HELP YOU FLOAT THROUGH ALL OF IT WITH SPEED AND CONTROL.

KEY PERFORMANCE FACTORS

Smooth control

Composite frameset is designed specifically for front suspension. With 40mm of travel, the fork absorbs bumps and impacts so you can ride smoother and faster over rugged gravel and dirt.

Tuned compliance

Lowered seatstays with smaller diameter tubes absorb road shocks and vibrations. A Contact SL XR D-Fuse handlebar adds more compliance without sacrificing the stiffness needed for cornering, sprinting or climbing.

Adaptable to the terrain

A flip chip on the rear dropout adjusts the wheelbase: short for quicker handling, or long for improved stability at speed. The long setting also allows for larger diameter tyres up to 53mm. You can use the included dropper/suspension seatpost for added capabilities, or switch to a proprietary D-Fuse seatpost or traditional 30.9mm round seatpost.

HIGHLIGHTS

The Advanced composite frameset is designed with suspension-optimised geometry and paired with a 40mm travel fork, delivering a smooth, controlled ride quality on rugged gravel and dirt. A flip chip on the rear dropout lets you adjust the wheelbase and increase tyre clearance up to 53mm. You can use the included dropper post, switch to a proprietary Giant D-Fuse seatpost for added compliance, or use a standard 30.9mm round seatpost. A Contact SL XR D-Fuse handlebar further minimises fatigue by absorbing shocks and vibrations.

Revolt X Advanced Pro with interactive tooltips

TECHS & FEATURES

Advanced Composite Technology
D-Fuse Technology
Flip Chip - Dropout
OverDrive
Tubeless System

SIZING GUIDE AND GEOMETRY

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

  • S
    159 cm to 171 cm
  • M
    169 cm to 181 cm
  • ML
    174 cm to 186 cm
  • L
    179 cm to 191 cm
  • XL
    189 cm to 200 cm
bike diagram with measurements referenced in table that follows
SMMLLXL
SHORT|LONGSHORT|LONGSHORT|LONGSHORT|LONGSHORT|LONG
ASEAT TUBE LENGTH(mm)450470490510530
BSEAT TUBE ANGLE73.5°|73.4°73.5°|73.4°73.0°|72.9°73.0°|72.9°73.0°|72.9°
CTOP TUBE LENGTH(mm)553560575585600
DHEAD TUBE LENGTH(mm)100115130145160
EHEAD TUBE ANGLE71.0°|70.9°71.5°|71.4°72.0°|71.9°72.0°|71.9°72.0°|71.9°
FFORK RAKE(mm)4545454545
GTRAIL(mm)76.9|80.373.5|76.870.1|73.470.1|73.470.1|73.4
HWHEELBASE(mm)1024|10341026|10361031|10411041|10511057|1067
ICHAIN STAY LENGTH(mm)425|435425|435425|435425|435425|435
JBOTTOM BRACKET DROP(mm)68|6968|6968|6968|6968|69
KSTACK(mm)560576592607621
LREACH(mm)387389393399410
MSTAND OVER HEIGHT(mm)736|743755|761772|778790|796808|814
NHANDLEBAR WIDTH(mm)440460460480480
OSTEM LENGTH(mm)6070808080
PCRANK LENGTH(mm)170172.5172.5175175
QWHEEL SIZE700c700c700c700c700c
  • Sizes
    S, M, M/L, L, XL
  • Colours
    Gloss Cordovan/Copper Coin
  • Frame
    Advanced-Grade Composite, 12x142mm thru-axle, disc, flip chip dropout
  • Fork
    RockShox Rudy Ultimate XPLR, 40mm, Charger Race Day damper 12x100mm thru-axle
  • Shock
    N/A
  • Handlebar
    Giant Contact SL XR D-Fuse, 16-degree flare S:44cm, M:46cm, M/L:46cm, L:48cm, XL:48cm
  • Grips
    Stratus Lite 3.0
  • Stem
    Giant Contact, 8-degree S:60mm, M:70mm, M/L:80mm, L:80mm, XL: 80mm
  • Seatpost
    Postmodern, dropper, 30.9mm with 25mm of suspension 415mm length / 100mm drop
  • Saddle
    Giant Approach SL
  • Pedals
    PEDALS NOT SUPPLIED
  • Shifters
    SRAM Rival eTap AXS, 1x12
  • Front Derailleur
    N/A
  • Rear Derailleur
    SRAM GX Eagle AXS
  • Brakes
    SRAM Rival eTap AXS hydraulic, SRAM PaceLine rotors [F]160mm, [R]160mm
  • Brake Levers
    SRAM Rival eTap AXS hydraulic
  • Cassette
    SRAM XG-1275, 12-speed, 10x52
  • Chain
    SRAM GX Eagle
  • Crankset
    SRAM Rival D1 DUB, 40t S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
  • Bottom Bracket
    SRAM DUB, press fit
  • Rims
    Giant CXR X1 Carbon Disc WheelSystem, [F] 25.8mm, [R] 25.8mm
  • Hubs
    [F] Giant AR alloy, CenterLock, 12mm thru-axle [R] Giant AR alloy, DT350 36t ratchet system, CenterLock, 12mm thru-axle
  • Spokes
    Sapim CX-Ray
  • Tyres
    Giant CrossCut Grip 1, 700x45c, tubeless
  • Extras
    Factory tubeless set up, 53mm max tyre size in "long" flip chip position, 45mm max tyre size in "short" flip chip position
  • Weight
